Icemedal IMT10 10Tons Per Day Tube Ice Machine for Ice Factory
Certification：CE
MOQ：1 set
Warranty：12 months
Payment：T/T, Western Union, Money Gram, L/C
Lead time：40 days after getting deposit
After-sales Service Provided：Engineers available to service overseas
- Description
- Specifications
- Details
- Features
Icemedal IMT10 10Tons Per Day Tube Ice Machine for Ice Factory
Intrduction of Porduct
The tube ice machine is an ice making machine. It is named for its ability to produce hollow ice of irregular length. The outer diameter of the ice tube is φ22mm, φ28mm, φ35mm, etc. and the length is between 25~45mm, and the inner diameter can be adjusted during the ice forming process usually between φ5~10mm.
The ice tube is thick and crystal clear, not easy to melt. The gas permeability is good so it is widely used in daily food, fruit and vegetable preservation, aquatic products preservation, etc.
10 ton tube ice machine is a split type ice machine. The ice making part is set apart from the main body, so that you can design the ice plant in a better way to use all the space. It is recommended to equip a screw type ice storage with cold source. Then the tube ice could last over night before packing.
Product Features
Daily Production 10 ton
3D designed to ensure the container transportation. Easy for installation & maintaining
Evaporator uses stainless steel & PU foam insulation, tunnels are insulated to save energy and good looking.
CE Certificate Approved
Special water system design to make ice good and evenly thickness, clear and pure
Unique ice harvesting way to make the process quick and low shock, more efficient and safer.
Special oil balance system has solved the oil loss problem that always happened in large capacity tube ice machine.
Product Details
Product Applicationuct Applicatiion
Frozen food preservation, medical applications, KTV, banquet hall, drinks modulation, hotels, hotels, bars, westernrestaurants, fast food shops, cold drinks shop, beer room and other places need ice.
Service Advantage
Icemedal implemented a professional,comprehensive and ONE-STOP management model,and created advanced technology,high-quality products and professional services.
has a number of patents,our products are widely used in cold chain logistics trans-portation,heat removal in vegetables and fruits fields,food processing,aquatic product processing,chemical industry,concrete mixing,mine cooling and other fields.
Our products has been exported to more than 130 countries and regions such us Africa,the Middle East,South Asia,Australia and South America.
Quality assurance
We through ISO,CE system certification,in line with national norms and standards.
Strict control of each process to ensure quality from the source.
Modern Factory
Focus on the field of industrial refrigeration equipment.
Production equipment have passed many domestic test and certifications.
The company adheres to the concept of“integrity,win-win,enjoy life”and is committed to building a modular factory for our customers.
After sales service
installation and commissioning guidance are available on site.
24 hr online multilingual services.
one year warranty,lifetime maintenance.
FAQ
| 1.Q:What is the ice making time of tube ice machine? |
| A:There are three sizes of pipe ice: pipe diameter 22mm, 28mm and 35mm, pipe diameter 22mm, ice making time 18-20 minutes; The pipe diameter is 28mm, and the ice making time is 20-22 minutes; The pipe diameter is 35mm, and the ice making time is 22-25mm minutes. |
| 2.Q:What brand does the compressor use? |
| A:It mainly adopts two brands: German Bezier compressor and American Valley wheel. When the voltage is 220V / 3P / 60Hz, the compressor of American Valley wheel is usually used; In other cases, the compressor of German bizel is generally used. |
| 3.Q:How to transport and install equipment? |
| A:After the goods arrive at the port of destination, forklifts need to be arranged, and the machinery is relatively heavy. we will tested and install well the machine before shipment, all necessary spare parts,operation,manual and CD are provided to guide the installation. We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer. |
| 4,Q:What is the price, what is the daily maintenance, and does it need to be looked after? |
| A:The prices of various models are different. Please consult the salesman for details. Keep the unit clean and sanitary, and clean the scale of water tank and evaporator from time to time. Check whether the apron pipe of the apron is blocked. There are still many details to pay attention to we will provide the operation manual. |
| Model | TONS/DAY capacity | Compressor Power(KW) | Circulating water pump power(KW) | Cooling water pump power(KW) | Cooling fan power(KW) | Ice cutting motor power(KW) | Ice machine dimensions(MM) | Weight(KG) |
| IMT1 | 1 | 3 | 0.37 | 1.1 | 0.18 | 0.75 | 1100*900*1780 | 900 |
| IMT2 | 2 | 6 | 0.55 | 1.5 | 0.37 | 0.75 | 1250*1000*1950 | 1200 |
| IMT3 | 3 | 9 | 0.75 | 1.5 | 0.56 | 0.75 | 1300*1100*2200 | 1500 |
| IMT5 | 5 | 18.75 | 1.5 | 2.2 | 0.75 | 1.5 | 1600*1400*2250 | 1800 |
| IMT10 | 10 | 37.5 | 1.5 | 4 | 1.5 | 1.5 | 1200*1200*31002300*1550*1800 | 3500 |
| IMT15 | 15 | 45 | 1.5 | 5.5 | 1.5 | 1.5 | 1500*1200*4500 2700*1950*2250 | 4250 |
| IMT20 | 20 | 75 | 2.2 | 7.5 | 2.2 | 2.2 | 1600*1300*47003100*2200*2250 | 6500 |
| IMT30 | 30 | 112.5 | 2.2 | 11 | 2.2 | 2.2 | 3000*2200*2500 2200*1900*6200 | 7200 |
1.Top Brand Compresso,Bitzer from Germany, Copeland from America, those are the compressor brands we use for your better ice machine.
2.Special Pipe Insulation,Aluminum pipe insulation is using insulating material and aluminum surface to cover the evaporator and pipe, to increase the efficient of ice making.
3.Danfoss Pressure Protector,The system is protected by Danfoss pressure protector to ensure the stable pressure. The products from Danfoss have better quality and accuracy.
1.Daily Production 10 ton
2.3D designed to ensure the container transportation. Easy for installation & maintaining
3.Evaporator uses stainless steel & PU foam insulation, tunnels are insulated to save energy and good looking.
4.CE Certificate Approved
5.Special water system design to make ice good and evenly thickness, clear and pure
6.Unique ice harvesting way to make the process quick and low shock, more efficient and safer.
7.Special oil balance system has solved the oil loss problem that always happened in large capacity tube ice machine.
